Full Spectrum of
  Embedded Wireless
  and OEM Solutions

Enabling Developers and Innovators with OEM-Friendly Wireless Technologies

WPANWLANWMAN
SATELLITE, GPS
WWAN



Featured Embedded Products

WPAN

RFID, ZigBee, Bluetooth, 802.15.4
High-Frequency (HF 13.56 MHz) RFID module, smallest on the market, can be software configured to support a variety of interfaces (UART/TLL, I2C, SPI). Industry's most secure multi-protocol embedded HF RFID reader, 7 programmable PPIO pins ISO 7816 smart card slot
BLUETOOTH PAN1310, tiny footprint -100 mm2 (11.6 x 8.7 x 1.8 mm), class 2 module (range up to 10 meters). Ideal for power sensitive projects World's First ZigBee SDIO card with WinCE Drivers
ZIGBEE PAN4555, a short range, low power, 2.4 GHz ISM band transceiver. ZIGBEE PAN4570, short range, low power, 2.4 GHz ISM band transceiver using the Ember EM250 single chip solution for ZigBee

WLAN

WiFi 802.11a/b/g, 900 MHz, 2.4 GHz, 4.9 GHz, 5 GHz
High Power (400mW) Industrial Temp. 802.11a/b/g mini-PCI (Atheros AR5414A-B2B) OEM 802.11b/g Compact Flash Stamp-Size Module with 2 diversity antenna connectors.
OEM 802.11b/g Surface Mount / SDIO Module (Marvell Chipset) OEM 802.11b/g Compact Flash Card w/ (2) external diversty antenna connectors (Broadcom chipset)
End-User 802.11b/g SDIO WLAN Card (Marvell chipset) End-User 802.11b/g Compact Flash WLAN Card (Marvell chipset)
High-Power 200mW WLAN 802.11b/g USB Adaptor w/ Removable Antenna (Atheros chipset) High-Power 100mW WLAN 802.11b/g Ethernet RJ45 (Adaptor / Bridge / AP) (No Drivers Needed!!)

WMAN

Metropolitan Area: Point to Point, Point to Multi-Point, Mesh Networks.
4-Radio Mesh (Three 802.11a + 802.11g Radios) with 64mW or 400mW RF Output 3-Radio Mesh: (Two 802.11a + 802.11g mode), with 64mW or 400mW RF Output

WWAN

Cellular Technologies: GSM GPRS, GSM / EDGE, CDMA, Data Plans
Wavecom Q24 Plus Quad-Band GSM/GPRS Voice/Data Module Wavecom Q2687 Quad-Band GSM / EDGE Voice/Data ARM9 Module
MTCAB-G-F4
GSM / GPRS class 10
GSM 900/1800 , 850/1900 MHz		 SIM Card

Data Plans available in 100 kB, 250 kB, 500 kB, 1 MB, 2 MB, 5 MB, 10 MB. SIM cards are perfect for M2M communication.


SATELLITE (GPS)

GPS Modules, GPS Receivers, GPS Dataloggers, etc.
Leadtek 9101 GPS mini-SMD (SiRF Star III / LP) Leadtek 9548S (9548SLP)
Evermore DL-600BT Wireless BT interface and GPS Data Logger EW-BTR900S3 Bluetooth GPS Receiver with Rechargable Li-ion Battery

ANTENNA

Variety of antenna types (surface mount, indoor, outdoor), frequencies, gain, etc.
2.4 GHz Surface Mount Antenna w/ 4.4 dBi Gain, 12.6x3.9x1.1 [mm] World's most efficient
Surface Mount GPS Antenna
Ideal for mobile GPS Devices
GPS Active Antenna has 28 dB gain, Magnetic Base, Waterproof housing (IP65 rated), and 5 meters (16 ft.) cablet) 5 dBi Quad-Band Antenna
2.4/ 4.9 / 5.2 / 5.8 GHz
RP-SMA or RP-TNC
Connector Options
2.4 GHz [ 16 dBi ]
Panel Antenna
(Vertical Polarization)		 2.4 GHz [ 19 dBi ]
Grid Parabolic Antenna

Accessories

RF Accessories for Any Wireless Project
4-to-1 mini-PCI to PCI Adaptor w/ RP-TNC Connector Holes Pigtail 7 (RG178) + U.FL / i-PEX + RP-SMA female bulkhead


Please join us to help support the relief efforts for these recent world disasters.
China Earthquake Relief
Myanmar Cyclone Relief
In recent years, the tremendous growth and interest in wireless technologies can be attributed to trends such as:
  • Global Acceptance of
    Standards-based RF Protocols:
    ~ RFID, ZigBee, Bluetooth,
    ~ 802.11abgn WiFi, WiMAX,
    ~ GSM/GPRS, EDGE, CDMA,
    ~ SATELLITE - GPS

  • Widespread Use of
    Wireless-enabled Devices:
    ~ Smartphones, PDA, Headsets,
    ~ Laptops, Access Points, etc.

  • Declining RF Chipset Costs Allowing for Vertical Markets:
    ~ Citywide WLAN, Hotspots,
    ~ Inventory Management,
    ~ Remote Asset Tracking, etc.

  • Simplified RF Solutions for Developers and Integrators:
    ~ OEM modules, SDK,
    ~ Variety of bus interfaces,
    ~ Precertified devices (FCC),
    ~ Open-source drivers, etc    .

Embedded Works Corporation is a value-added distributor and design integrator of embedded wireless technologies. Whether your company is implementing a wireless product for the first time, or developing the next generation wireless design, our unique industry expertise and wireless product-line can help meet your roadmap objectives!

Embedded Works is more than a OEM hardware provider, we can assist you with your development needs to get your product to production. Whether you need assistance with porting device drivers to (Linux, WindowsCE, custom O/S), or getting your RF hardware designed and/or manufactured, visit our Design Services pages to find out how we can help you shave off man-months (or years) off your product launch schedule.

We've updated our website to present to you the latest wireless technology choices available today, and tomorrow! Visit any product category on our PRODUCTS MAIN PAGE, then order engineering samples to test in your lab. We'll be glad to help you with your design proto-typing problems, and work with you to make your product / project a success.

Wirelessly yours,
Embedded Works
